LS30

Hanging LED Aluminum Profile for Office Lighting

33.6*75 mm Aluminum Profile for Hanging Lighting with 15°30°45°Reflector

Basic parameters

Model:
LS30
Material:
Extruded Aluminum{6063-T5)
Size:
33.6×75mm
Diffuser:
PC frosted cover
Installation:
Pendant
Finish:
Silver / Black anodized , Powder coated white / black or other colors

Optical Parameter

Colour: 2700K/3000K/4000K
Max Power: 30W/m
Max LED Strip Width: 24mm
Beam angle: 100°(PC frosted cover)
Tolerance: 士1%
IP: 20
